| Technical data |
HY880M |
| Output Power(RMS) |
50W |
| Frequency response |
Mic :-3dB (200Hz~5KHz) Line:-3dB(100Hz~20kHz) |
| THD at 1kHz |
Less than 1% |
| Input sensitivity |
Input 1 Mic :-50dB(2.45mV)/2 k ohms, unbalanced |
| Input 2 Mic :-50dB(2.45mV)/2 k ohms, unbalanced |
| Input 3 Aux :-10dB(245mV)/5 k ohms ,unbalanced |
| Output Interface |
70 V and 100V |
| Low-impedance output (8 ohms)low-impedance outputs(4,8,16 ohms) |
| Signal-to-noise ratio |
Mic:>70dB Line:>80dB |
| Power consumption |
DC 12V/4A |
| AC220V/0.5A |
| Power supply |
110/220V (AC 50-60-Hz) main power 12VDC |
| Dimensions :W*H*D |
250*85*250 |
